Compact unit OVB 88 kW/230 V

The design of heat exchangers is specially designed for heating pool water, water in whirlpools and spas or for underfloor heating. The use of this all-stainless steel heat exchanger is optimal when heating water with a gas or other boiler, heat pump, or solar collectors. The design of the heat exchanger is designed with regard to the limitation of the flow so as to ensure the supply of heat to the maximum extent and at the same time to minimize the pressure in the heating system. Heat exchangers - compact units. Only to order. Exchanger compact unit - composed of: Heat exchanger (brass/plastic 1.5"/50 mm screw outlets. Wilo circulation pump (on the primary circuit 1"). Sinks for the temperature sensor of the thermostat. Electric automatics with current protector, fuses and switching elements that control the water temperature, switching of the filter device with the thermostat. The whole set is mounted on the board
